Trident ECO
Economical (Entry Level) Cleaning System for Low-Medium Production

• Removes Any Flux From Any Alloy
• Closed-Loop (Zero Discharge) Wash Cycle
• Low Discharge Rinse Cycle
• Automatic Wash, Rinse, and Dry Cycles
• Unlimited Program Recipes
• Graphic User Touchscreen Interface
• Entry-Level Pricing

Trident ECO offers the cleaning power of Trident in a lower cost, longer cycle time configuration. Equipped with an asymmetrical fan-jet spray system, Trident ECO's twin stainless steel counter rotating spray bars feature twenty stainless steel fan-jet nozzles project precision-diffused wash solution and rinse water onto a shadow-mitigating oscillating board rack. This spray system was implemented to deliver controlled fluid energy underneath fine-pitch components. Trident ECO includes a closed loop (zero discharge) wash solution section and an low-discharge rinse section.

Features:

• Dimensions: 42 1/4"D x 47 3/4"W x 70"H
• Electrical Requirements: 208-240 3Ø 40 amps
• Chemical Dosing and Mixing: Manual
• Control System: Windows 7 PC User Interface Touchscreen
• Advanced SPC Data Collection
• Assembly Barcode Scanning Capability
• Built-In Cleanliness Monitor: Optional
• Construction: Welded Steel Tube Frame with Steel Panels
• Finish: Baked Powder-Coat Hammer-Tone Finish
• Plumbing Materials: Stainless Steel
• Fluid Delivery Technology: 20 Asymmetrically Placed 15° Stainless Steel Nozzles
• Number of Process Chambers: 1 Standard (2-4 Optional)
